Overview

The ABB AX522 1SAP250000R0001 Analog Input/Output Module is a versatile solution designed for integration with ABB’s AC500 automation platform. This module facilitates precise signal measurement and output control, making it ideal for complex industrial environments. With 8 analog inputs and 8 analog outputs, it supports a variety of signal types, including voltage, current, and RTD sensors such as PT100, PT1000, and NI1000.

Functional Highlights

The AX522 module offers 4 current outputs (0–20 mA / 4–20 mA) and 4 voltage outputs (up to ±10 V), providing flexible analog signal transmission for diverse applications. The input ranges from -10 to +10 V and 0 to +10 V, making it suitable for monitoring and control in process automation, building systems, and manufacturing settings.

Moreover, the ABB AX522 delivers a 12-bit resolution plus sign, ensuring accurate and reliable signal processing. Its compact design (54 x 76 x 68 mm) and lightweight (approximately 0.14 kg) allow for easy DIN rail mounting, making it a space-efficient module. The IP20 protection rating ensures that it remains safe from dust and other environmental factors.

The module operates on a 24 V DC power supply and can be installed horizontally or vertically, with derating considerations for vertical setups. Additionally, it enhances I/O capacity in scalable automation systems and is fully supported by ABB’s Control Builder PS501-PROG software environment.

Technical Data

• Model Number: AX522 1SAP250000R0001
• Module Type: Analog Input/Output Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.14 kg
• Dimensions: 8.5 x 7 x 7 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS (Distributed Control System)
• Status: Active
• Input Types: Voltage, Current, RTD (PT100, PT1000, NI1000)
• Input Range: -10 to +10 V, 0 to +10 V
• Current Outputs: 0–20 mA / 4–20 mA
• Voltage Outputs: Up to ±10 V
• Resolution: 12 bits (plus sign)
• Power Supply: 24 V DC
• Protection Rating: IP20

Typical Applications

The ABB AX522 Analog Input/Output Module is suitable for:

• Process automation applications requiring precise signal control
• Building systems with varied monitoring requirements
• Manufacturing environments where robust I/O capabilities are essential
• Integrating RTD sensors and analog signals into automation control systems

FAQ

1. What is the weight of the AX522 Analog Input/Output Module?
   The AX522 weighs approximately 0.14 kg.

2. What are the dimensions of this module?
   Its dimensions are 8.5 x 7 x 7 cm.

3. How many inputs and outputs does the AX522 support?
   It features 8 analog inputs and 8 analog outputs.

4. What types of sensors does the AX522 accommodate?
   It supports voltage, current, and RTD sensors (PT100, PT1000, NI1000).

5. What is the resolution of the input/output signals?
   The module offers a resolution of 12 bits.
