Overview

The ABB AI835A 3BSE051306R1 Analog Input Module is an advanced 8-channel device designed for high-precision acquisition of thermocouple and millivolt signals. Engineered for industrial environments, this module supports a wide variety of thermocouple types, including J, K, T, E, R, S, B, N, and C, with an input range of ±200 mV. Its versatility makes it ideal for temperature measurement applications in critical industrial settings.

Functional Highlights

This analog input module ensures exceptional accuracy, providing a resolution of 0.1 μV and an overall accuracy of ±0.1% of full scale. The AI835A is built to minimize noise, operating at levels below 5 μVrms, which enhances the reliability of readings in electrically noisy environments. Additionally, the temperature drift is minimal, less than 50 μV/°C, which ensures stable performance over time.

Moreover, the AI835A features continuous wire-break detection and allows one channel to be configured for cold junction compensation using a 4-wire Pt100 RTD. Operating on a 24 V DC power supply, this module boasts low energy consumption, making it efficient for long-term use. Designed for DIN rail mounting, it facilitates seamless integration into control cabinets.

The AI835A’s robust construction enables it to withstand harsh conditions, functioning reliably in temperatures ranging from -20 to +70 °C. This capability makes it an optimal choice for process control, data acquisition, and machine automation applications that require high-density precision temperature monitoring.

Technical Data

• Model Number: AI835A 3BSE051306R1
• Module Type: Analog Input Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 1.08 kg
• Dimensions: 18.5 x 8.5 x 30.5 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS
• Status: Active
• Input Channels: 8
• Supported Thermocouples: J, K, T, E, R, S, B, N, C
• Input Range: ±200 mV
• Resolution: 0.1 μV
• Accuracy: ±0.1% of full scale
• Noise Level: < 5 μVrms
• Temperature Drift: < 50 μV/°C
• Operating Temperature: -20 to +70 °C
• Power Supply: 24 V DC

Typical Applications

The ABB AI835A 3BSE051306R1 Analog Input Module is suitable for:

• High-precision temperature measurement in industrial processes
• Data acquisition systems requiring reliable signal integrity
• Machine automation applications where temperature monitoring is critical
• Environments with large variations in temperature and electrical noise
