Overview

The ABB GDC806C0003 3BHE044249R0003 PCB Card is a highly reliable and precision-engineered drive board, crucial for ABB's advanced motor control systems. This module is specifically designed to deliver outstanding performance in industrial automation applications, ensuring real-time responsiveness and optimal control in demanding environments.

Functional Highlights

With an exceptional measurement update speed of less than 40 milliseconds, the GDC806C0003 ensures quick response times for critical control tasks. It features channel-wise electrical isolation, which maintains signal integrity while adhering to a voltage rating of 250Veff in compliance with EN 50020 standards.

Moreover, this PCB card operates with minimal energy consumption, requiring only 600mW of connected load while maintaining precise control. The intelligent current limiting feature (≤28.5mA) combined with a low no-load voltage (≤21V) provides both safety and performance optimization, making this module ideal for precision motion control applications.

The robust design of the GDC806C0003 allows for seamless integration with ABB's automation platforms, offering engineers flexible configuration options. Its compact dimensions enable space-efficient installation in control cabinets, ensuring functionality without occupying excessive space.

Technical Data

• Model Number: GDC806C0003 3BHE044249R0003
• Module Type: PCB Card
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.15 kg
• Dimensions: 17 x 8.2 x 5 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Compatibility: Advant OCS/800xA
• Voltage Rating: 250Veff
• Energy Consumption: 600mW (connected load)
• Measurement Update Speed: <40 ms
• Current Limiting: ≤28.5 mA
• No-load Voltage: ≤21V

Typical Applications

The ABB GDC806C0003 PCB Card is suitable for:

• Precision motion control in manufacturing processes
• Industrial automation systems requiring reliable performance
• Conveyor systems and pumps needing efficient control solutions
• Any applications within the Advant OCS/800xA ecosystem that demand high reliability and responsiveness
