Overview

The ABB PFPK122 3BSE013036R1 Circuit Board is a versatile signal conditioning module specifically designed for industrial automation applications. This compact unit operates on 24V DC (±10%) and consumes low power, offering flexible integration with various field devices. Its robust design and advanced features make it an excellent choice for demanding environments.

Functional Highlights

The PFPK122 Circuit Board supports both 24V DC digital I/O and 4-20mA/0-10V analog signals, which allows for a wide range of applications. With reinforced isolation of 1500V AC (field-to-system) and 250V AC channel-to-channel isolation, this module ensures reliable operation even in electrically noisy environments.

Moreover, the PFPK122 maintains stable performance across a wide operating temperature range of -25°C to +70°C, with storage capabilities from -40°C to +85°C. The module also boasts a humidity resistance of 5-95% (non-condensing), making it suitable for use in manufacturing plants and other process facilities that encounter varying conditions.

The PFPK122 excels in distributed control applications because of its combination of analog and digital signal processing. Its compact design and compatibility with DIN-rail mounting simplify installation in control cabinets while maintaining high-density I/O capabilities.

As part of ABB's industrial automation portfolio, the PFPK122 Circuit Board provides reliable signal conditioning essential for critical monitoring and control tasks. The module's robust electrical isolation and wide temperature operation make it ideal for applications requiring precise data acquisition in challenging environments.

Technical Data

• Model Number: PFPK122 3BSE013036R1
• Module Type: Circuit Board
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.4 kg
• Dimensions: 6 x 25.8 x 24.3 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Range of Product: Advant OCS/800xA
• System Type: DCS
• Power Supply: 24V DC (±10%)
• Power Consumption: ≤4W
• Isolation: 1500V AC (field-to-system), 250V AC (channel-to-channel)
• Operating Temperature Range: -25°C to +70°C
• Storage Temperature Range: -40°C to +85°C
• Humidity Tolerance: 5-95% non-condensing

Typical Applications

The ABB PFPK122 Circuit Board is suitable for:

• Industrial automation processes requiring reliable signal conditioning.
• Manufacturing plants and process facilities facing variable environmental conditions.
• Distributed control applications needing both analog and digital signal processing.

FAQ

1. What is the weight of the PFPK122 Circuit Board?
   The PFPK122 weighs 0.4 kg.

2. What are the dimensions of the PFPK122?
   Its dimensions are 6 x 25.8 x 24.3 cm.

3. What types of signals does the PFPK122 support?
   It supports both 24V DC digital I/O and 4-20mA/0-10V analog signals.

4. What is the operating temperature range of the PFPK122?
   The operating temperature range is -25°C to +70°C.

5. What kind of isolation does the PFPK122 provide?
   It has 1500V AC (field-to-system) and 250V AC (channel-to-channel) isolation.
