Overview

The ABB PM511V16 3BSE011181R1 Processor Module is a high-performance processor module designed for the AC400 controller system. This robust processor unit serves as the central computing component in industrial automation applications. It utilizes a powerful 25 MHz Motorola 68040 processor and comes equipped with 16 Mbytes of dynamic RAM that incorporates Error Correcting Code (ECC) for enhanced data integrity and system reliability. This module is essential for handling complex control algorithms and meeting real-time processing requirements in demanding industrial environments.

Functional Highlights

A notable feature of the PM511V16 is its PCMCIA slot, which allows the use of flash memory cards for system software storage and updates. This enhances the module's versatility in managing software configurations. The standard configuration includes two SIMM memory modules, and users can opt for different memory capacities with an available 8 MB version. Flexibility is further provided with adjustable memory configurations through specific switch settings, making the module adaptable to various application needs.

Moreover, the PM511V16 is designed to operate in harsh environments. It is offered in a coated marine-classified version to protect against moisture, corrosion, and other environmental factors, ensuring reliable performance in challenging industrial conditions.

With a robust construction, the PM511V16 delivers long-term reliability in diverse settings such as manufacturing plants and process industries. This processor module is at the heart of distributed control systems, managing complex automation tasks and coordinating multiple I/O modules effectively.

Technical Data

• Model Number: PM511V16 3BSE011181R1
• Module Type: Processor Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 1.22 kg
• Dimensions: 24 x 19 x 5.3 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Range of Product: Advant OCS/800xA
• System Type: DCS
• Processor Type: Motorola 68040
• Processor Speed: 25 MHz
• RAM: 16 Mbytes with ECC
• Flash Memory: User-defined via PCMCIA
• Operating Temperature Range: -25°C to +60°C
• Humidity Range: 5-95% (non-condensing)
• Power Supply Voltage: 24V DC
• I/O Interface: Supports multiple I/O modules

Typical Applications

The ABB PM511V16 Processor Module is ideal for:

• Distributed control systems in power generation and chemical processing.
• Automotive and manufacturing automation processes requiring robust computing power.
• Systems in need of reliable operation under varying environmental conditions.

FAQ

1. What is the weight of the PM511V16 Processor Module?
   The PM511V16 weighs 1.22 kg.

2. What are the dimensions of the PM511V16?
   Its dimensions are 24 x 19 x 5.3 cm.

3. What is the processor speed of the PM511V16?
   It features a 25 MHz Motorola 68040 processor.

4. What is the maximum operating temperature for the PM511V16?
   The module operates effectively from -25°C to +60°C.

5. Does the PM511V16 offer memory customization options?
   Yes, users can adjust memory configurations through specific switch settings.
