Overview

The ABB SDCS-POW-H01 3ADT318700R1501 Power Supply Board is a dedicated 24V DC module specifically designed for ABB DCS800 drive systems. This robust unit operates within a 20-30V DC input range while also supporting an optional 100-240V AC input (50/60Hz), providing exceptional flexibility for global industrial applications. The SDCS-POW-H01 delivers a stable continuous current of 5-10A with a peak capacity of 15A, ensuring uninterrupted power for critical drive components.

Functional Highlights

Engineered to withstand harsh environments, the SDCS-POW-H01 features advanced protection against voltage fluctuations and electrical noise. Its compact design integrates seamlessly with DCS800 cabinets, while the dual-input capability (both DC and AC) offers versatile installation options. Furthermore, the module's efficient power conversion minimizes energy loss, maintaining optimal performance in continuous operation scenarios.

This power supply board excels in demanding applications such as metal processing, mining, and material handling. Its industrial-grade components and reinforced insulation comply with stringent safety standards, while the wide operating temperature range ensures reliability under extreme conditions. The plug-and-play design simplifies maintenance, significantly reducing system downtime.

The SDCS-POW-H01 Power Supply Board delivers the stability required for precision motor control. Its combination of high current capacity, input flexibility, and rugged construction makes it an ideal choice for heavy-duty industrial automation systems worldwide.

Technical Data

• Model Number: SDCS-POW-H01 3ADT318700R1501
• Module Type: Power Supply Board
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.45 kg
• Dimensions: 20.2 x 9.7 x 4.2 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Lead Time: In Stock
• Minimum Order Quantity (MOQ): 1
• Input Voltage Range: 20-30V DC or 100-240V AC
• Output Voltage: 24V DC
• Continuous Current Output: 5-10A
• Peak Current Capacity: 15A
• Operating Temperature Range: Suitable for harsh conditions
• Protection Features: Voltage fluctuation and electrical noise protection

Typical Applications

The ABB SDCS-POW-H01 Power Supply Board is suitable for:

• Industrial automation systems requiring robust power supply management.
• Metal processing and mining applications that demand high reliability.
• Material handling systems where consistent power delivery is critical.

FAQ

1. What is the weight of the SDCS-POW-H01 Power Supply Board?
   The SDCS-POW-H01 weighs 0.45 kg.

2. What are the dimensions of the SDCS-POW-H01?
   Its dimensions are 20.2 x 9.7 x 4.2 cm.

3. What input voltage range does the SDCS-POW-H01 accept?
   It can operate within a 20-30V DC range and supports 100-240V AC input.

4. What is the continuous current output of the SDCS-POW-H01?
   The board delivers a continuous current output of 5-10A.

5. In what applications is the SDCS-POW-H01 most commonly used?
   It is commonly used in metal processing, mining, and material handling.
