Overview

The ABB XF801 3BSE061579R1 Fast I/O Module is a robust PROFIBUS DP interface module designed for seamless integration within industrial automation systems. Operating on a 24 VDC input voltage, this module provides reliable communication with a maximum output current of 0.5A per channel. Its primary purpose is to connect field devices efficiently to control systems, making it an essential component for modern automation setups.

Functional Highlights

This industrial control module features exceptional electrical isolation, with 500 VAC channel-to-channel and 1500 VAC channel-to-backplane protection, enhancing system safety. The XF801 operates reliably across a wide temperature range of -25°C to +60°C and can handle humidity levels of 5-95% non-condensing, making it suitable for various industrial environments.

Moreover, its compact DIN-rail mounted design saves panel space while withstanding industrial vibrations and electrical noise. With a low power consumption of ≤5W, the XF801 presents an energy-efficient solution for automation cabinets. The module offers superior isolation capabilities, preventing ground loops and protecting sensitive equipment.

This module supports high-speed PROFIBUS DP communication, achieving speeds of up to 12 Mbps. LED indicators provide instant status monitoring, simplifying maintenance and troubleshooting processes. The 24 VDC (±10%) power supply via backplane ensures stable operation even during voltage fluctuations, further cementing its reliability.

Technical Data

• Model Number: XF801 3BSE061579R1
• Module Type: Fast I/O Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.3 kg
• Dimensions: 16.5 x 16 x 8 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Lead Time: In Stock
• Minimum Order Quantity (MOQ): 1
• Operating Voltage: 24 VDC
• Output Current per Channel: 0.5 A
• Electrical Isolation: 500 VAC channel-to-channel, 1500 VAC channel-to-backplane
• Temperature Range: -25°C to +60°C
• Humidity: 5-95% non-condensing
• Power Consumption: ≤5 W
• Communication Protocol: PROFIBUS DP (up to 12 Mbps)

Typical Applications

The ABB XF801 Fast I/O Module is ideally suited for:

• Power generation facilities where efficient communication is critical.
• Oil and gas operations requiring robust data transmission capabilities.
• Manufacturing automation systems that demand reliable integration of field devices.

Support & Maintenance

ABB provides comprehensive support for the installation and maintenance of the XF801 Fast I/O Module. Our dedicated team ensures that you receive assistance when integrating this module into your industrial systems, guaranteeing optimal performance.
