Overview

The ABB TU810V1 3BSE013230R1 Compact Module Termination Unit (MTU) is a state-of-the-art signal conditioning solution designed for industrial automation systems. As a pivotal component of the S800 I/O system, this module provides precise conversion and isolation of various signal types, such as 4-20 mA current loops, 0-10 V voltage signals, and thermocouple inputs.

Functional Highlights

Engineered for exceptional performance, the TU810V1 features robust 1500V galvanic isolation, effectively eliminating ground loops and minimizing electrical interference in challenging environments. Its compact and high-density design optimizes control cabinet space, while ensuring excellent thermal performance within a wide temperature range of -25°C to +70°C.

Moreover, the module comes equipped with intuitive LED diagnostic indicators that provide real-time status updates, enhancing maintenance efficiency in critical process applications. The hot-swappable design further simplifies serviceability, allowing for easy replacement without disrupting operations.

One of the standout attributes of the TU810V1 is its remarkable immunity to electromagnetic disturbances, ensuring reliable operation in electrically noisy factories. Its flexible architecture seamlessly integrates with ABB's 800xA control system, and its compliance with stringent international standards guarantees dependable performance in various global industrial applications.

Technical Data

• Model Number: TU810V1 3BSE013230R1
• Module Type: Compact Module Termination Unit
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.22 kg
• Dimensions: 17 x 6.5 x 6.5 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Lead Time: In Stock
• Minimum Order Quantity (MOQ): 1
• Operating Temperature Range: -25°C to +70°C
• Galvanic Isolation Rating: 1500V

Typical Applications

The ABB TU810V1 Compact Module Termination Unit is ideal for:

• Signal conditioning in oil refineries, power generation stations, and manufacturing facilities.
• Integration within the ABB 800xA control system for enhanced process automation.
• Environments with challenging electrical conditions requiring robust signal isolation.

FAQ

1. What is the weight of the TU810V1 Compact Module?
   The TU810V1 weighs 0.22 kg.

2. What are the dimensions of this module?
   Its dimensions are 17 x 6.5 x 6.5 cm.

3. What types of signals can the TU810V1 handle?
   It can manage 4-20 mA, 0-10 V, and thermocouple signals.

4. What is the operational temperature range of the TU810V1?
   The unit operates efficiently between -25°C and +70°C.

5. How does the TU810V1 ensure reliable operation?
   Its robust galvanic isolation and immunity to electromagnetic disturbances protect against interference.
