Overview

The ABB UF C784 AE101 3BHE003688R0101 Circuit Board is a high-performance module specifically designed for ABB's AC 800PEC and 800xA control systems. This versatile module supports various platforms including Symphony Melody, Advant OCS, and Harmony/INFI 90 systems, ensuring seamless integration into diverse industrial automation applications.

Functional Highlights

Engineered for reliability, the 3BHE003688R0101 operates at 24V DC and functions within a temperature range of -20°C to 60°C, which makes it suitable for demanding industrial environments. Its compact design, measuring 44.8 x 17.3 x 4.2 cm and weighing 2.8 kg, allows for easy installation in confined spaces.

Moreover, this circuit board demonstrates exceptional compatibility across ABB's product range, including Freelance DCS and MOD 300 software platforms. It seamlessly integrates with industrial robot spare parts from the DSQC series and other systems, enhancing its appeal for comprehensive automation solutions.

The module's robust construction and wide operating temperature range ensure optimal performance even in harsh conditions, making it an ideal choice for power plants and manufacturing facilities. The proven stability and efficiency of the ABB UF C784 AE101 3BHE003688R0101 make it a critical component in distributed control systems for process industries.

Technical Data

• Model Number: 3BHE003688R0101
• Module Type: Circuit Board
• Manufacturer: ABB
• Condition: Brand New
• Weight: 2.8 kg
• Dimensions: 17.3 x 44.8 x 4.2 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Lead Time: In Stock
• Minimum Order Quantity (MOQ): 1
• Operating Voltage: 24V DC

Typical Applications

The ABB UF C784 AE101 Circuit Board is ideal for:

• Power generation plants requiring reliable control over industrial processes.
• Manufacturing facilities needing versatile and robust control solutions.
• Industrial automation systems that require seamless integration across multiple platforms.

Support & Maintenance

ABB provides comprehensive support for the installation and maintenance of the UF C784 AE101 module. Our skilled team ensures that the circuit board operates optimally to meet your automation needs.

FAQ

1. What is the weight of the UF C784 AE101 Circuit Board?
   The UF C784 AE101 weighs 2.8 kg.

2. What are the dimensions of this circuit board?
   Its dimensions are 17.3 x 44.8 x 4.2 cm.

3. What is the voltage requirement for the UF C784 AE101?
   It operates at 24V DC.

4. Is the module compatible with other ABB systems?
   Yes, it integrates with various ABB products, including Freelance DCS and MOD 300.

5. What is the operating temperature range?
   The module functions reliably within -20°C to 60°C.
