Overview

The ABB GJR2393200R1210 88TK05C-E Bus Coupling Module serves as an essential component within the Procontrol P14 diagnostic architecture. This module acts as a Station-Bus Coupler, leveraging the power of individual microprocessors within each I/O unit for comprehensive self-monitoring and diagnostics. Its design enables seamless communication between various components, enhancing system reliability in industrial automation applications.

Functional Highlights

One of the key benefits of the GJR2393200R1210 88TK05C-E is its ability to continuously communicate operational status to the Control Diagnostic System (CDS). This system graphically displays all components in real-time, providing operators with immediate insight into the health of the entire setup.

Moreover, through the CDS interface, the station-bus coupler can be visually identified by its cabinet location, with its operational state indicated by color coding. This visual representation allows operators to quickly access the diagnostic register of the Bus Coupling Module, offering detailed information on functionality and health.

In addition, in the event of a failure, the system guides users by highlighting the specific module and providing a clear description of the fault cause. This integrated diagnostic approach significantly enhances system reliability and reduces troubleshooting time. Therefore, this module is crucial for maintaining uninterrupted operations in complex industrial environments.

Technical Data

• Model Number: GJR2393200R1210 88TK05C-E
• Module Type: Bus Coupling Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 1.22 kg
• Dimensions: 24 x 19 x 5.3 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Compatibility: Procontrol P14
• Communication Service: Ethernet router

Typical Applications

The ABB GJR2393200R1210 88TK05C-E Bus Coupling Module is ideal for:

• Industrial automation systems that require reliable data communication.
• Integration and coordination of distributed control systems in power plants.
• Applications needing real-time diagnostic and monitoring capabilities.
• Enhancements to existing systems without interruption of service.

FAQ

1. What is the weight of the GJR2393200R1210 Bus Coupling Module?
   The module weighs 1.22 kg.

2. What are the dimensions of this module?
   Its dimensions are 24 x 19 x 5.3 cm.

3. How does the module communicate the operational status?
   It communicates status through the Control Diagnostic System (CDS).

4. What features assist in troubleshooting?
   The module highlights faults and provides descriptions of the causes.

5. Is the module suitable for power plant use?
   Yes, it is suitable for use in complex industrial automation environments.
