Overview

The ABB AO810V2 3BSE038415R1 Analog Output Module is a high-density solution designed for the Symphony Plus control system. It provides critical control signals in industrial process automation, ensuring reliable performance in demanding environments. With eight independent output channels, this module excels in producing precise 0(4)-20 mA current signals, essential for accurately managing field actuators, valves, and other final control elements.

Functional Highlights

The AO810V2 module features a remarkable 14-bit resolution, enabling fine-tuning of process variables in applications such as chemical processing, power generation, and water treatment. Its robust drive capability supports a load impedance of up to 500 Ohms on all channels simultaneously or 850 Ohms on a single channel. This flexibility allows seamless interfacing with various field devices without the need for additional signal conditioning equipment.

Moreover, the module connects through specific termination units including TU810, TU812, TU814, TU830, or TU833. These units provide necessary wiring interfaces and signal conditioning, ensuring reliable operation in electrically noisy industrial environments while maintaining signal integrity across all channels.

With compact dimensions of 45mm (W) x 119mm (H) x 102mm (D) and a net weight of just 1.22 kg, the ABB AO810V2 makes efficient use of space in control cabinet layouts. This space-saving design, coupled with substantial functionality, makes it an ideal choice for modern distributed control systems.

Furthermore, the module complies with RoHS environmental directives and falls under WEEE category 5, reflecting ABB's commitment to environmental responsibility. The AO810V2 serves as a reliable interface between digital control systems and analog field devices, converting digital commands into precise analog signals to manipulate process variables.

Technical Data

• Model Number: AO810V2 3BSE038415R1
• Module Type: Analog Output Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 1.22 kg
• Dimensions: 24 x 19 x 5.3 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS (Distributed Control System)
• Status: Active
• Output Channels: 8 channels
• Output Current: 0(4)-20 mA
• Resolution: 14 bits
• Load Impedance: 500 Ohms (all channels), 850 Ohms (single channel)
• Operating Temperature Range: -25°C to +60°C
• Protection Class: IP20

Typical Applications

The ABB AO810V2 Analog Output Module is suitable for:

• Industrial automation systems needing precise analog control
• Applications in chemical processing and power generation
• Water treatment plants requiring accurate process variable manipulation
• Systems that demand robust performance in challenging environments

FAQ

1. What is the weight of the AO810V2 Analog Output Module?
   The AO810V2 module weighs 1.22 kg.

2. What are the dimensions of this module?
   Its dimensions are 24 x 19 x 5.3 cm.

3. How many output channels does the AO810V2 have?
   The module provides 8 independent output channels.

4. What is the accuracy of the AO810V2?
   The module has a resolution of 14 bits for precise signal output.

5. Is the AO810V2 suitable for harsh industrial environments?
   Yes, it is designed to operate effectively from -25°C to +60°C.
