Overview

The ABB BINT-12C 3AXD50000803385 Circuit Interface Board is a high-performance interface designed for use with ABB's ACS880-104-R8I drives. This essential component ensures reliable and accurate communication between various system elements, making it a vital part of industrial automation setups. With its compact printed circuit board (PCB) layout, it integrates seamlessly into facilities where reliability and efficiency are paramount.

Functional Highlights

Operating on a 24 V DC input (±10%), the BINT-12C Circuit Interface Board supports numerous digital I/O interfaces, making it versatile for demanding control environments. It is exclusively compatible with ZCU units, ensuring optimal performance within a temperature range of -15°C to +55°C.

Moreover, the board supports firmware versions FW2.51 and above, allowing for enhanced multi-programming capabilities. The ABB BINT-12C also offers a service license for on-site programming, which adds convenience for field engineers involved in real-time installations or maintenance tasks.

Designed specifically for the ACS880-14/-34 drive systems, this interface board guarantees dependable performance and easy integration into existing systems. Always confirm compatibility by checking the drive type from the rating label or DIB before installation.

Technical Data

• Model Number: BINT-12C 3AXD50000803385
• Module Type: Circuit Interface Board
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.24 kg
• Dimensions: 17 x 8.2 x 7 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS (Distributed Control System)
• Status: Active
• Input Voltage: 24 V DC (±10%)
• Temperature Range: -15°C to +55°C
• Compatibility: Designed for ACS880-14 and ACS880-34 drives
• Firmware Support: FW2.51 and above

Typical Applications

The ABB BINT-12C Circuit Interface Board is ideal for:

• Integration with ACS880 drive systems in industrial automation
• Environments requiring precise communication between control components
• Applications where reliable I/O operations are critical
• Setup and maintenance in power generation and distribution systems

FAQ

1. What is the weight of the BINT-12C Circuit Interface Board?
   The BINT-12C weighs 0.24 kg.

2. What are the dimensions of this interface board?
   Its dimensions are 17 x 8.2 x 7 cm.

3. What input voltage does the BINT-12C require?
   It operates on a 24 V DC input with ±10% tolerance.

4. Which firmware versions are supported by the BINT-12C?
   It supports firmware versions FW2.51 and above.

5. What temperature range can the BINT-12C operate in?
   It operates within a temperature range of -15°C to +55°C.
