Overview

The ABB CCU-24-H 3AXD50000018771 Control Unit is a compact and efficient module designed for industrial automation applications. Engineered by ABB, this control unit is ideal for integration with ACS880 series drives, providing advanced control, stability, and superior processing performance. Its small footprint allows for installation in space-constrained environments without sacrificing functionality.

Functional Highlights

Operating at a power supply of 24 V DC ±10%, the CCU-24-H boasts a low power consumption of approximately 5 W, contributing to its energy efficiency. With 64 MB of RAM, this control unit ensures smooth operation and rapid data handling. The module supports two analog output channels, configurable as either 0–10 V or 4–20 mA, offering flexibility for interfacing with various devices within automation systems.

Moreover, the ABB CCU-24-H is built for durability, with an operating temperature range of -20°C to +60°C. It can even withstand storage temperatures as low as -40°C and humidity levels of 5% to 95% (non-condensing), making it suitable for harsh industrial environments. The dimensions of the unit, at 8.5 x 7.5 x 7.5 cm and a lightweight design of 0.16 kg, enhance its installation flexibility.

Manufactured in Sweden and readily available, the ABB CCU-24-H Control Unit is a trusted component in industrial control, ensuring reliable performance and seamless integration in various automation scenarios.

Technical Data

• Model Number: CCU-24-H 3AXD50000018771
• Module Type: Control Unit
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.16 kg
• Dimensions: 8.5 x 7.5 x 7.5 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS
• Status: Active
• Supply Voltage: 24 V DC ±10%
• Power Consumption: Approx. 5 W
• RAM: 64 MB
• Analog Output Channels: 2 (Configurable: 0–10 V or 4–20 mA)
• Operating Temperature Range: -20°C to +60°C
• Storage Temperature Range: Down to -40°C
• Humidity Resistance: 5% to 95% (non-condensing)

Typical Applications

The ABB CCU-24-H Control Unit is perfect for:

• Integration with ACS880 series drives in automation systems
• Applications requiring precise control and monitoring
• Industrial environments where space is limited
• Scenarios that demand high processing performance and reliability

FAQ

1. What is the weight of the CCU-24-H Control Unit?
   The weight of the CCU-24-H module is 0.16 kg.

2. What are the dimensions of this control unit?
   Its dimensions are 8.5 x 7.5 x 7.5 cm.

3. What is the power supply requirement for the CCU-24-H?
   It operates at a supply voltage of 24 V DC ±10%.

4. How much power does the CCU-24-H consume?
   The unit consumes approximately 5 W of power.

5. What is the operating temperature range for the CCU-24-H?
   The operating temperature range is -20°C to +60°C.
