Overview

The ABB DI801 3BSE020508R1 Digital Input Module is a reliable 16-channel module specifically designed for the S800 I/O system. This module excels in industrial automation applications, ensuring high performance in demanding environments.

Functional Highlights

Featuring a voltage range of 18 to 30 V DC and a current consumption of 6 mA at 24 V, the DI801 provides efficient signal processing. Each of the 16 input channels is grouped into one isolated section to enhance protection against electrical noise and interference.

Moreover, the DI801 module includes current-limiting components, EMC protection, LED status indicators, and optical isolation for each channel. The 16th channel has the added capability for voltage supervision, enabling real-time monitoring of the input group’s voltage status. This set of features enhances reliability and durability, making it suitable for environments with significant electromagnetic interference.

The DI801 is designed to protect both the module and connected devices from voltage spikes and electrical disturbances, ensuring safe operation. Its advanced EMC and optical isolation technologies make it an ideal choice for process control, automation systems, and equipment status monitoring. As a result, the DI801 delivers excellent protection and performance, essential for demanding industrial applications.

Technical Data

• Model Number: DI801 3BSE020508R1
• Module Type: Digital Input Module
• Manufacturer: ABB
• Condition: Brand New
• Range of Product: S800 I/O
• Weight: 0.36 kg
• Dimensions: 11.8 x 13.6 x 8.3 cm
• HS CODE: 8537101190
• Communication Service: Ethernet router
• System: DCS
• Status: Discontinued (as of Dec 31, 2018)
• Minimum Order Quantity: 1
• Product Origin: Sweden

Typical Applications

The ABB DI801 Digital Input Module is suitable for a wide range of applications, including:

• Process control in manufacturing environments
• Status monitoring of equipment and machinery
• Automation systems requiring reliable input signal processing
• Systems where protection from electrical interference is critical

Its robust design and extensive features make it a crucial component in various industrial automation settings.

FAQ

1. What is the weight of the DI801 module? The module weighs 0.36 kg.

2. What dimensions does the DI801 Digital Input Module have? The dimensions are 11.8 x 13.6 x 8.3 cm.

3. What voltage range does the DI801 support? It supports a voltage range of 18 to 30 V DC.

4. How many input channels does the DI801 have? The DI801 has 16 digital input channels.

5. What features enhance the reliability of the DI801 module? It includes current limiting, EMC protection, and optical isolation to ensure reliability and durability.
