Product Overview:
The Bently Nevada 330180-50-05 Proximity Sensor is a highly reliable 5-meter extension cable designed for the 3300 XL Proximitor Sensor system. This robust cable assembly ensures effective signal transmission between proximity probes and monitoring equipment, even in demanding industrial environments. By maintaining signal integrity in high-interference areas, this proximity sensor is essential for accurate monitoring in applications such as turbines, compressors, and other rotating equipment.
Technical Specifications:
Model Number: 330180-50-05
Module Type: Proximity Sensor
Manufacturer: Bently Nevada
Condition: Brand New
Product Range: 3300 Proximity Transducer System
Lead Time: In Stock
Weight: 0.22 kg
Dimensions: 8.5 x 3.5 x 7 cm
HS CODE: 8537101190
Product Origin: USA
System: TSI
Communication Service: Ethernet Router
Model Code Breakdown:The model number 330180-50-05 can be broken down as follows:
330180: Identifies the product as part of Bently Nevada's 3300 series.
50: Indicates the specific configuration and features of the proximity sensor.
05: Denotes additional attributes or adaptations relevant to the design and functionality of the sensor.
Installation Recommendations and Wiring Guide:To achieve optimal performance with the Bently Nevada 330180-50-05 Proximity Sensor, follow these guidelines:
Select an Appropriate Installation Location: Ensure that the sensor is positioned where it can effectively transmit signals from the proximity probes to the monitoring equipment.
Mounting the Sensor: Utilize the provided panel-mount configuration, which shares a 4-hole footprint compatible with legacy systems. Ensure the mounting is secure to minimize vibration interference.
Connecting the Cable: The sensor features SpringLoc terminal technology, eliminating screw-type connections. Connect the cable securely to prevent loosening from vibration.
Testing the Setup: After installation, perform thorough testing to confirm functionality and reliability of the signal transmission.
Frequently Asked Questions (FAQ):
Q: What is the primary use of the Bently Nevada 330180-50-05 Proximity Sensor?
A: It is used for reliable signal transmission between proximity probes and monitoring systems in industrial environments.
Q: How long is the extension cable?
A: The 330180-50-05 Proximity Sensor features a 5-meter (16.4-foot) cable.
Q: Can this sensor be used in hazardous locations?
A: Yes, it meets CSA, ATEX, and IECEx certifications, making it suitable for hazardous environments.
Q: What advantages does the SpringLoc technology provide?
A: This technology prevents the loosening of connections due to vibration, ensuring consistent performance.
Q: Is installation complex?
A: No, the design simplifies installation, allowing for both DIN-rail and traditional panel setups without the need for shielded conduit.
