Overview
The Honeywell MLI-DR30E Base Module is a compact and versatile industrial interface module designed to provide reliable signal conditioning and control in various automation applications. It is equipped with an extensive power supply range of 100-240V AC, making it suitable for diverse industrial environments. This module supports 18 DC 24V input channels and 12 relay output channels, allowing for flexible operation in demanding settings.
Functional Highlights
Key features and benefits of the Honeywell MLI-DR30E include:
-
Wide AC Power Supply Range: Operates efficiently with a voltage range of 100-240V, ensuring compatibility with different power systems.
-
High-Speed Processing: Achieves a processing speed of 240 nanoseconds per step, facilitating quick response times for control operations.
-
Flexible Programming Capacity: Supports up to 128 programs with a total capacity of 50kB (4k steps), providing extensive application options for automation scenarios.
-
Photo-Coupler Isolation: Utilizes photo-couplers for enhanced safety and reliability, minimizing the risk of electrical faults.
Key Benefits:
-
Reliable Output Performance: Each output channel supports a load voltage of DC 12/24V and a maximum load current of 0.5A per point, or 2A per common terminal.
-
Durability in Demanding Conditions: Built to handle maximum load capacities of AC 250V or DC 125V at 2A, ensuring stable performance even in challenging environments.
-
Compact Design: Measures 24.5 cm x 16 cm x 13.5 cm and weighs 1.3 kg, making it a suitable choice for installations where space is limited.
Technical Data
-
Model Number: MLI-DR30E
-
Module Type: Base Module
-
Manufacturer: Honeywell
-
Condition: Brand New
-
Weight: 0.4 kg
-
Dimensions: 24.5 cm x 16 cm x 13.5 cm
-
HS CODE: 8537101190
-
Product Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Input Channels: 18 DC 24V
-
Output Channels: 12 Relay outputs
-
Power Supply Range: 100-240V AC
-
Processing Speed: 240 ns per step
-
Maximum Load Capacity: AC 250V or DC 125V at 2A
Typical Applications
The Honeywell MLI-DR30E Base Module is suitable for:
- Industrial automation applications requiring reliable signal conditioning and control.
- Systems that demand high-speed processing and flexibility in programming.
- Environments where safety and reliability are critical, such as manufacturing plants and facilities.
Support & Maintenance
Honeywell provides comprehensive support for the MLI-DR30E Base Module. Our technical team is available for installation assistance, troubleshooting, and ongoing maintenance to ensure optimal performance in your automation systems.
FAQ
-
What is the primary function of the MLI-DR30E Base Module?
It provides reliable signal conditioning and control for various automation applications.
-
How many input and output channels does this module support?
It features 18 input channels and 12 relay output channels.
-
What is the operating power supply range of this module?
It operates within a range of 100-240V AC.
-
What is the processing speed of the MLI-DR30E?
The module achieves a processing speed of 240 nanoseconds per step.
-
Is this module suitable for harsh industrial environments?
Yes, it is designed to handle demanding conditions while maintaining reliable performance.
