Overview

The ABB CI801 3BSE022366R1 Profibus DP-VI Communication Interface Module is a highly adaptable Fieldbus Communication Interface (FCI) module designed to enhance communication within the S800 I/O system. This powerful module facilitates seamless and efficient data exchange between distributed I/O modules and parent controllers or PLCs. Its robust construction and advanced features make it suitable for demanding process control applications across various industries, including oil & gas, power generation, and manufacturing.

Functional Highlights

A standout feature of the CI801 module is its support for the PROFIBUS-DPV1 fieldbus, which provides high-speed and deterministic communication essential for modern industrial applications. The module performs vital functions such as signal processing, supervision data collection, and Operator Station Panel (OSP) handling.

Moreover, the CI801 supports Hot Configuration InRun, enabling modifications without system downtime. It also features HART pass-through capabilities for improved device diagnostics, ensuring that operators can effectively maintain and configure connected devices.

The flexibility of the CI801 module allows for easy configuration and integration with multiple I/O modules, while its modular design supports scalability. Advanced diagnostics and monitoring functionalities enhance reliability, making it ideal for use in various environments, including hazardous and complex industrial setups.

Technical Data

• Model Number: CI801 3BSE022366R1
• Module Type: Profibus DP-VI Communication Interface Module
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.26 kg
• Dimensions: 13.5 x 9 x 5.7 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS
• Status: Active
• Fieldbus Support: PROFIBUS-DPV1
• Hot Configuration: InRun supported
• HART Pass-through: Yes

Typical Applications

The ABB CI801 module is perfect for:

• Enhancing communication in S800 I/O systems
• Integration with ABB’s 800xA control systems
• Process control in oil & gas and power generation sectors
• Environments requiring reliable communication in industrial automation

FAQ

1. What is the weight of the CI801 module?
   The CI801 module weighs 0.26 kg.

2. What are the dimensions of the CI801 module?
   Its dimensions are 13.5 x 9 x 5.7 cm.

3. What kind of communication does the CI801 support?
   It supports PROFIBUS-DPV1 fieldbus communication.

4. Can the CI801 be configured without downtime?
   Yes, it supports Hot Configuration InRun.

5. What industries can the CI801 be used in?
   It is used in oil & gas, power generation, and manufacturing industries.
