Overview

The ABB CDP312R Control Panel is a versatile and intuitive display unit designed for industrial automation applications. Featuring a clear LCD screen capable of displaying 4 lines with 20 characters each, this control panel allows operators to interact effectively with various automation processes. Notably, the CDP312R supports multiple languages during startup, enabling accessibility for international users. Its reliable construction makes it suitable for demanding industrial environments.

Functional Highlights

This control panel provides comprehensive control capabilities to enhance operational efficiency. The ACT key activates Actual Signal Display Mode for real-time monitoring, while the PAR key accesses the Parameter Mode for system configuration. Additionally, the FUNC key allows for advanced operations, and the DRIVE key provides easy selection between different drive configurations. This flexibility makes the CDP312R adaptable to a variety of automation scenarios.

Moreover, the CDP312R features a sophisticated navigation system that includes single arrow keys for basic scrolling and double arrow keys for rapid movement through menus, significantly speeding up navigation. An ENTER key confirms selections, with each key's function dynamically adapting to the current operation mode, thus minimizing the potential for operational errors.

The ABB CDP312R is commonly integrated with ABB's AC 500 PLC systems, providing operators with comprehensive visibility and control over automation parameters. This rugged panel is built to endure the challenges of industrial environments while maintaining a user-friendly interface.

Technical Data

• Model Number: CDP312R
• Module Type: Control Panel
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.16 kg
• Dimensions: 7.8 x 2 x 17 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• System Type: DCS
• Status: Active

Typical Applications

The ABB CDP312R Control Panel is ideal for:

• Integration with ABB ACS800 series drives
• User interface in industrial automation applications
• Providing real-time monitoring and parameter adjustment in control processes
• Environments that require multilingual support for global operations

FAQ

1. What is the weight of the CDP312R Control Panel?
   The weight of the CDP312R is 0.16 kg.

2. What are the dimensions of this control panel?
   Its dimensions are 7.8 x 2 x 17 cm.

3. What kind of display does the CDP312R have?
   It features an LCD screen with 4 lines and 20 characters per line.

4. Can the CDP312R support multiple languages?
   Yes, the control panel allows users to select their preferred language during startup.

5. What systems is the CDP312R commonly integrated with?
   It is commonly integrated with ABB's AC 500 PLC systems.
