Overview

The ABB PFEA112-20 3BSE050091R20 Tension Controller is a sophisticated tension electronics module designed for precise web tension control in continuous manufacturing processes. This DIN-rail mounted unit provides accurate processing of signals from dual load cells with a ±0.1% accuracy rating, making it ideal for applications in industries like paper, plastic, and textiles.

Functional Highlights

The PFEA112-20 enhances the core functionality of the PFEA111 series by incorporating PROFIBUS-DP communication, enabling seamless integration into automated production lines. It features both 0-10VDC and 4-20mA analog outputs with an impressive response time of ≤1 ms, ensuring quick adjustments to tension levels.

Additionally, the module is equipped with a 2x16 character display that provides real-time tension data, including sum, difference, and individual load cell values. Users can easily configure settings via equipped parameter adjustment keys, allowing for quick adaptations to production needs. The PFEA112-20 operates on a flexible power supply of 24VDC (±10%) or 100-240VAC while consuming ≤10W, promoting energy-efficient performance.

Available in both IP20 (DIN-rail) and IP65 (NEMA 4) enclosures, the module fits various environmental conditions, from clean control rooms to harsher factory settings. It operates effectively within a temperature range of 0°C to +55°C and tolerates humidity levels of 5-95% non-condensing, ensuring reliable performance across diverse production scenarios.

With its PROFIBUS-DP interface, the PFEA112-20 enhances real-time tension monitoring in Industry 4.0 environments. Additionally, the module’s multi-language interface and fieldbus capabilities cater to global operations requiring precise web tension management in converting, printing, and textile applications.

Technical Data

• Model Number: PFEA112-20 3BSE050091R20
• Module Type: Tension Controller
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.3 kg
• Dimensions: 8.5 x 13.6 x 5.2 cm
• HS CODE: 8537101190
• Product Origin: Sweden
• Range of Product: ABB
• Power Supply: 24VDC (±10%) or 100-240VAC
• Power Consumption: ≤10W
• Output Types: 0-10VDC and 4-20mA
• Response Time: ≤1 ms
• Operating Temperature Range: 0°C to +55°C
• Humidity Tolerance: 5-95% non-condensing
• Enclosures: IP20 (DIN-rail) and IP65 (NEMA 4)

Typical Applications

The ABB PFEA112-20 Tension Controller is highly suitable for:

• Continuous manufacturing processes requiring accurate tension control.
• Industries such as converting, printing, and textiles.
• Automated production lines utilizing advanced control systems.

FAQ

1. What is the weight of the PFEA112-20 Tension Controller?
   The PFEA112-20 weighs 0.3 kg.

2. What are the dimensions of the PFEA112-20?
   Its dimensions are 8.5 x 13.6 x 5.2 cm.

3. What types of outputs does the PFEA112-20 provide?
   It offers 0-10VDC and 4-20mA analog outputs.

4. What power supply options does the PFEA112-20 support?
   It operates on 24VDC (±10%) or 100-240VAC.

5. What is the operating temperature range of the PFEA112-20?
   The operating temperature range is 0°C to +55°C.
