Overview

The ABB SDCS-FEX-425-INT 3ADT209022R0001 Control Field Exciter Board is a robust and versatile fieldbus extension module designed for modern industrial automation applications. Manufactured by ABB, this module ensures seamless integration within control systems and provides reliable communication between devices, making it an excellent choice for various industrial processes.

Functional Highlights

Operating on a supply voltage of 24 VDC with a power consumption of approximately 10–20 W, the SDCS-FEX-425-INT operates efficiently in demanding environments. It features a wide voltage range of 0–250 VDC and a current range of 0–20 A, making it suitable for diverse industrial applications.

One of its standout features is the strong isolation capability, with input-to-output isolation rated at 2500 VAC. This enhances both safety and signal integrity, crucial factors in industrial settings. The module supports analog inputs of 4–20 mA or 0–10 V, providing compatibility with a wide range of sensors and transmitters.

Moreover, this exciter board operates reliably in temperatures from -20°C to +70°C, with extreme storage capabilities from -40°C to +85°C. Its compact dimensions (27 x 11.5 x 6 cm) and lightweight design (0.66 kg) facilitate easy installation, especially in space-constrained environments.

The ABB SDCS-FEX-425-INT is also designed to withstand humidity levels of 5–95% (non-condensing), ensuring consistent operation even in harsh or humid conditions.

Technical Data

• Model Number: SDCS-FEX-425-INT 3ADT209022R0001
• Module Type: Control Field Exciter Board
• Manufacturer: ABB
• Condition: Brand New
• Weight: 0.66 kg
• Dimensions: 27 x 11.5 x 6 cm
• Supply Voltage: 24 VDC
• Power Consumption: 10–20 W
• Voltage Range: 0–250 VDC
• Current Range: 0–20 A
• Isolation Rating: 2500 VAC
• Temperature Range: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Communication Protocol: Analog inputs 4–20 mA or 0–10 V
• Humidity Tolerance: 5–95% (non-condensing)
• HS CODE: 8537101190
• Product Origin: Sweden
• Lead Time: In Stock
• Minimum Order Quantity (MOQ): 1

Typical Applications

The ABB SDCS-FEX-425-INT Control Field Exciter Board is ideal for:

• Integration into industrial control systems requiring high reliability and precision.
• Applications in power generation, manufacturing, and process control.
• Environments where robust signal integrity and safety are essential.
