Overview

The Honeywell CC-GDIL21 Digital Input Module is a highly versatile and reliable component designed for seamless integration with Honeywell's comprehensive control system portfolio. This compact module features eight isolated digital input channels specifically engineered for 24 VDC signals, providing robust functionality in various industrial applications. The CC-GDIL21 is particularly valuable for applications requiring reliable ON/OFF condition detection and pushbutton input capabilities, all within a single module.

Functional Highlights

Key features of the Honeywell CC-GDIL21 include:

• Eight Isolated Input Channels: Designed for 24 VDC signals, ensuring reliable connections and operational efficiency.
• Wide Voltage Range: Supports operational voltages from 18 to 26.4V DC for ON states and 5.0V DC or less for OFF states.
• Rapid Response Times: Input processing achieves a response of 8 ms or less for status monitoring and a minimum of 20 ms for pushbutton detection.

Key Benefits

• Dual-Function Capability: This module supports both standard ON/OFF condition detection and counting input from pushbutton actuations, enhancing its utility in diverse applications.
• Safety Features: The module includes comprehensive diagnostics, such as open-wire detection, which identifies faults in field wiring and prevents incorrect control actions.
• Galvanic Isolation: Provides electrical separation between field devices and control systems, ensuring safe operation in hazardous environments.

Technical Data

• Model Number: CC-GDIL21
• Module Type: Digital Input Module
• Manufacturer: Honeywell
• Condition: Brand New
• Weight: 0.4 kg
• Dimensions: 7 cm x 14 cm x 14.5 cm
• HS CODE: 8537101190
• Product Origin: USA
• Lead Time: In Stock
• Minimum Order Quantity (MOQ): 1
• Input Signal Voltage: 24 VDC (operational voltage 18 to 26.4V DC)
• Maximum Input Voltage: 30.0 VDC
• AC Withstand Voltage: 2 kV between input signals and system
• Input Processing Time: 8 ms for status, 20 ms minimum for pushbutton

Typical Applications

The Honeywell CC-GDIL21 is ideal for:

• Digital input monitoring in process industries requiring reliable performance.
• Integration into industrial automation systems where space is constrained.
• Applications needing robust human-machine interface functionality combined with standard discrete input capabilities.

Support & Maintenance

Honeywell provides comprehensive support for the CC-GDIL21 Digital Input Module. Our dedicated team is available to assist with installation, troubleshooting, and maintenance, ensuring optimal performance in your industrial applications.

FAQ

1. What is the main function of the Honeywell CC-GDIL21?
   The module serves as a versatile digital input device for monitoring ON/OFF conditions and pushbutton actuations.

2. What is the operational voltage range for this module?
   It supports an operational voltage range of 18 to 26.4V DC for ON states.

3. How quickly can the module process input signals?
   The input processing time is 8 ms or less for status monitoring and a minimum of 20 ms for pushbutton detection.

4. What safety features does this module include?
   It has open-wire detection to identify field wiring faults and provides galvanic isolation for electrical safety.

5. Is the CC-GDIL21 suitable for use in hazardous areas?
   Yes, it features a non-incendive field power supply, making it ideal for deployment in hazardous locations.
