Overview
The Honeywell 51153818-101 Jumper Kit is a crucial component designed for use within the Experion PKS C300 Control Systems. This specialized jumper kit includes ten pre-configured 22 AWG jumper cables, each measuring six inches, and is engineered to establish reliable electrical connections between I/O modules and the central PLC backplane. This product is vital for ensuring effective signal transmission and power distribution throughout the controller's modular components.
Functional Highlights
Key features of the Honeywell 51153818-101 include:
-
Standardized Design: The jumper kit's uniform design guarantees compatibility with various HC900 I/O modules, effectively reducing connection uncertainties during system assembly.
-
Time-Saving Installation: The pre-fabricated nature of the jumpers significantly decreases installation time compared to custom wiring solutions, providing a streamlined setup experience.
-
Robust PVC Insulation: Each jumper cable is insulated with durable PVC, protecting against accidental short circuits and environmental contaminants.
-
Ease of Maintenance: Facilitates quick module replacement without complex rewiring, allowing field technicians to efficiently swap out I/O modules while maintaining consistent backplane connections.
Key Benefits:
-
Enhanced Reliability: The standardized jumpers ensure consistent electrical characteristics across all connections, contributing to overall system reliability.
-
Durable Construction: Built to withstand industrial conditions, the kit ensures long-term connection integrity, even in environments characterized by vibration and temperature variations.
-
Optimal Jumper Quantity: The kit contains an adequate number of jumpers to support typical HC900 configurations, making it essential for both initial commissioning and ongoing maintenance operations.
Technical Data
-
Model Number: 51153818-101
-
Module Type: Jumper Kit
-
Manufacturer: Honeywell
-
Condition: Brand New
-
Weight: 0.4 kg
-
Dimensions: 7 x 14 x 14.5 cm
-
HS CODE: 8537101190
-
Product Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Jumper Length: 6 inches
-
Wire Gauge: 22 AWG
-
Insulation Material: PVC
Typical Applications
The Honeywell 51153818-101 Jumper Kit is ideal for:
- Use in the Experion PKS C300 control systems where reliable internal connections are essential.
- Environments that require frequent I/O module replacements without extensive rewiring.
- Industrial automation systems needing simplified setup and maintenance procedures.
Support & Maintenance
Honeywell offers extensive support for the 51153818-101 Jumper Kit. Our knowledgeable team is available to assist with installation guidance, troubleshooting, and any inquiries to ensure optimal performance within your automation framework.
FAQ
-
What is the weight of the Honeywell 51153818-101 Jumper Kit?
The weight is 0.4 kg.
-
What are the dimensions of this jumper kit?
Its dimensions are 7 x 14 x 14.5 cm.
-
How many jumper cables does the kit contain?
The kit comes with ten 22 AWG jumper cables.
-
What is the length of each jumper cable?
Each jumper cable is six inches long.
-
Is the jumper kit suitable for harsh industrial environments?
Yes, its durable PVC insulation protects against environmental contaminants and short circuits.
