Overview
The Honeywell CC-PDIS01 51405042-176 Digital Input Module is a high-performance component designed for industrial control systems. This module supports 32 input channels that accept 24VDC discrete signals, providing precise and reliable monitoring with a 1ms resolution for Sequence of Events (SOE) recording. Its robust design is suitable for safety-critical applications in process automation.
Functional Highlights
Key features of the Honeywell CC-PDIS01 include:
-
Flexible Operational Modes: The module offers three modes of operation: Normal (20ms PV scan), Sequence of Events (1ms SOE resolution), and Low Latency (5ms PV scan).
-
Extensive Internal Diagnostics: Includes diagnostic capabilities for data integrity and open-wire detection, ensuring consistent operation in critical environments.
-
Wide Voltage Range: Operates within a power supply range of 18 to 30 VDC, accommodating various system requirements.
-
High Input Sense Parameters: Features ON sense parameters of 13 VDC minimum and OFF sense parameters of 5 VDC maximum, providing flexibility for diverse applications.
Key Benefits:
-
Redundancy and Reliability: Optional redundancy capabilities and internal/external field power selection enhance system reliability.
-
Safety Features: Provides non-incendive field power with galvanic isolation, ensuring safety during operation.
-
User-Friendly Input Indication: Supports direct/reverse input indication to simplify diagnostics and monitoring.
Technical Data
-
Model Number: CC-PDIS01 51405042-176
-
Module Type: Digital Input Module
-
Manufacturer: Honeywell
-
Condition: Brand New
-
Weight: 0.4 kg
-
Dimensions: 24 x 18.8 x 6.5 cm
-
HS CODE: 8537101190
-
Product Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Channel Count: 32
-
Input Voltage Range: 18 to 30 VDC
-
ON Sense Parameters: Minimum 13 VDC / 3 mA
-
OFF Sense Parameters: Maximum 5 VDC / 1.2 mA
-
Operational Modes: Normal, Sequence of Events, Low Latency
-
Internal Diagnostics: Yes (open-wire detection)
Typical Applications
The Honeywell CC-PDIS01 is ideal for:
- Process automation systems requiring reliable digital input processing.
- Safety applications in manufacturing environments needing precise event sequencing.
- Industrial systems where real-time monitoring and control are essential to operational efficiency.
Support & Maintenance
Honeywell offers extensive support for the CC-PDIS01 module. Our team of experts is available for installation assistance, troubleshooting, and ongoing maintenance to ensure optimal performance within your automation processes.
FAQ
-
What is the weight of the Honeywell CC-PDIS01 module?
The weight is 0.4 kg.
-
What are the dimensions of this digital input module?
Its dimensions are 24 x 18.8 x 6.5 cm.
-
How many input channels does the module have?
It provides support for 32 input channels.
-
What is the operational voltage range for this module?
The operating voltage range is 18 to 30 VDC.
-
Does the module include diagnostic features?
Yes, it features extensive diagnostics, including open-wire detection.
