Overview
The Honeywell TC-CCR013 Redundant Net Interface Module is a state-of-the-art ControlNet module designed for high-availability automation systems. This robust component ensures continuous operation in critical environments by supporting dual redundant firmware and media. By providing a regulated 24V DC output from a 24V DC input, this module maintains seamless communication and control integrity within complex industrial networks.
Functional Highlights
Key features of the Honeywell TC-CCR013 include:
-
Redundant Design: Supports dual redundant firmware and media, enhancing system reliability and minimizing downtime in critical applications.
-
Temperature and Humidity Tolerance: Built to operate within a temperature range of -20°C to +50°C and withstands 5-95% relative humidity.
-
Maximum Output Current: Delivers up to 5A of continuous output current, providing consistent performance for demanding control tasks.
-
Compact Form Factor: Measures 3.8 x 16.8 x 13.2 cm and weighs just 0.3 kg, facilitating easy integration into existing ControlLogix systems.
Key Benefits:
-
Enhanced Reliability: The dual redundant capability helps prevent unplanned downtime, ensuring that industrial processes remain uninterrupted.
-
Improved Process Safety: By maintaining communication integrity, the TC-CCR013 contributes to safer operational environments.
-
Ease of Integration: This module’s design is focused on functionality, allowing for straightforward integration within established control architectures.
Technical Data
-
Model Number: TC-CCR013
-
Module Type: Redundant Net Interface Module
-
Manufacturer: Honeywell
-
Condition: Brand New
-
Product Range: Honeywell
-
Weight: 0.4 kg
-
Dimensions: 3.8 cm x 16.8 cm x 13.2 cm
-
HS CODE: 8537101190
-
Product Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Input Voltage: 24V DC
-
Output Voltage: 24V DC
-
Maximum Continuous Output Current: 5A
-
Operating Temperature Range: -20°C to +50°C
-
Humidity Tolerance: 5% to 95% non-condensing
Typical Applications
The Honeywell TC-CCR013 is ideal for:
- High-availability automation systems in various industries, including oil and gas, power generation, and manufacturing.
- Control systems requiring redundancy to enhance process reliability and safety.
- Environments where maintaining communication integrity is essential for operational efficiency.
Support & Maintenance
Honeywell provides comprehensive support for the TC-CCR013 Redundant Net Interface Module. Our expert team is available to assist with installation, configuration, and troubleshooting, ensuring optimal module performance in your systems.
FAQ
-
What is the primary function of the TC-CCR013 module?
It provides a redundant ControlNet interface for reliable communication in automation systems.
-
What is the maximum continuous output current for this module?
The TC-CCR013 delivers up to 5A of continuous output current.
-
What temperature range can this module operate within?
It operates effectively between -20°C and +50°C.
-
Can this module be integrated into existing ControlLogix systems?
Yes, its compact design allows for easy integration into established control architectures.
-
Does the module support redundancy?
Yes, it features dual redundant firmware and media for enhanced reliability.
