Overview
The Honeywell MLI-DP40SU Base Module is a technically advanced digital power supply module designed for use in industrial automation systems. As a critical component of the MasterLogic 50 series platform, this module delivers exceptional power management capabilities, ensuring reliable power distribution and signal conditioning for various control applications.
Functional Highlights
Key features of the Honeywell MLI-DP40SU include:
-
Comprehensive Power Management: With a 40-point configuration, it supports efficient power distribution to multiple industrial devices, enhancing overall system performance.
-
Wide AC Voltage Range: Operates on an AC voltage range from 100 to 240VAC, providing flexibility for global applications while ensuring stable performance.
-
Compact Design: Its dimensions of 90 x 135 x 64 mm make it ideal for space-constrained control cabinets without compromising functionality.
-
High-Speed Counter Functionality: Supports capabilities up to 100kHz, catering to precise motion control applications, including 2-axis positioning.
Key Benefits:
-
Energy Efficiency: Consumes only 355mA, contributing to reduced operational costs in demanding industrial environments.
-
Robust Communication: Features both RS-232 and RS-485 communication interfaces for seamless integration into industrial networks.
-
Flexible Programming Options: Supports multiple programming languages as per IEC 61131-3 standards, including ladder logic and function block diagram.
-
Wide Operating Temperature Range: Designed for optimal performance across temperatures from 0 to 55°C, with storage capabilities from -25 to 75°C.
Technical Data
-
Model Number: MLI-DP40SU
-
Module Type: Base Module
-
Manufacturer: Honeywell
-
Condition: Brand New
-
Weight: 0.4 kg
-
Dimensions: 7 x 14 x 14.5 cm
-
HS CODE: 8537101190
-
Product Origin: USA
-
Lead Time: In Stock
-
Minimum Order Quantity (MOQ): 1
-
Input/Output Configuration: 24 standard digital inputs, 16 digital outputs (open collector)
-
Integrated Program Memory: 15,000 steps
-
Maximum I/O Supported: 264 points
-
Current Consumption: 355mA
Typical Applications
The Honeywell MLI-DP40SU Base Module is ideal for:
- Advanced industrial automation applications requiring reliable power management and control.
- Systems that demand high-speed counting and precise motion control for operation.
- Environments where communication flexibility and programmability are essential for integration.
Support & Maintenance
Honeywell provides extensive support for the MLI-DP40SU module. Our expert team is available to assist with installation, configuration, and ongoing maintenance, ensuring the reliability and longevity of your automation systems.
FAQ
-
What is the weight of the Honeywell MLI-DP40SU module?
The weight is 0.4 kg.
-
What are the dimensions of this base module?
Its dimensions are 7 x 14 x 14.5 cm.
-
What is the operating voltage range for this module?
It operates on an AC voltage range of 100 to 240VAC.
-
How many digital inputs and outputs does it support?
It supports 24 digital inputs and 16 digital outputs.
-
What is the maximum I/O configuration for this module?
The module supports up to 264 I/O points.
