The Bently Nevada 330101-00-61-15-12-05 3300 XL 8 mm Proximity Probe is meticulously designed for precise monitoring of vibration and shaft position in various industrial machines. This high-performance probe ensures accurate measurement of both static (position) and dynamic (vibration) parameters, making it particularly suitable for fluid-film bearing machines. Its compact 8 mm size is optimized for applications requiring high precision in demanding environments, including Keyphasor® and speed measurement applications.
Designed for durability, the probe features a strengthened bond between the probe tip and body through the innovative TipLoc molding process, providing enhanced long-term stability. The patented CableLoc design allows for a robust pull strength of 330 N (75 lbf), securing the connection between the probe and cable, while the optional FluidLoc cable option prevents oil leaks, enhancing safety during operation.
The model number 330101-00-61-15-12-05 is structured as follows:
330101: Identifies the specific series and model within the Bently Nevada 3300 XL product line.
00: Indicates a standard configuration without special modifications.
61: Refers to specific design features of the probe.
15: Indicates the length or cable specification.
12: Refers to additional features or configurations available.
05: Signifies the specific performance and compatibility options.
| Parameter | Specification |
|---|---|
| Model Number | 330101-00-61-15-12-05 |
| Module Type | 3300 XL 8 mm Proximity Probe |
| Manufacturer | Bently Nevada |
| Condition | Brand New |
| Range of Product | 3300 XL Proximity Transducer System |
| Lead Time | In Stock |
| Weight | 0.06 kg |
| HS CODE | 8537101190 |
| Dimensions | 1.8 x 1.6 x 123 cm |
| Minimum Order Quantity (MOQ) | 1 |
| Product Origin | USA |
| System Compatibility | TSI |
| Discontinued | Active |
| Communication Service | Ethernet router |
| Operating Temperature Range | Wide range for industrial applications |
| Pull Strength | 330 N (75 lbf) |
| TipLoc Design | Enhanced bond for durability |
| Cable Option | FluidLoc optionally available |
For optimal performance of the Bently Nevada 330101-00-61-15-12-05 Proximity Probe, follow these installation guidelines:
Secure Mounting: Ensure that the probe is firmly attached, using the appropriate mounting practices to avoid misalignment during operation.
Cable Management: Employ the patented CableLoc design to secure the connection and protect against wear due to movement or bending.
Gap Calibration: Maintain proper gap specifications between the probe and the target surface to ensure accurate readings.
Fluid Management: If using the FluidLoc cable option, ensure a proper seal to prevent oil or liquid leakage, enhancing operational safety.
The Bently Nevada 330101-00-61-15-12-05 Proximity Probe offers several key advantages in industrial applications:
Durable Construction: The strong bond between the probe tip and body ensures long-term reliability and stability under demanding operational conditions.
High Precision Measurement: This probe excels in providing precise static and dynamic measurements, crucial for monitoring the health of large rotating machines.
RFI/EMI Resistance: Enhanced resistance to radio frequency and electromagnetic interference ensures stable performance in challenging environments.
Interchangeability: Fully compatible with other components in the 3300 XL series, this probe supports easy integration and replacement without extensive recalibration.
This combination of durability, precision, and versatility makes the Bently Nevada 330101-00-61-15-12-05 an essential tool for effective monitoring in demanding industrial environments.
Q1: What types of machines can the Bently Nevada 330101-00-61-15-12-05 Probe monitor?
A1: This probe is ideal for monitoring vibration and position in fluid-film bearing machines, as well as for Keyphasor® and speed measurement applications.
Q2: What is the purpose of the FluidLoc cable option?
A2: The FluidLoc cable option is designed to prevent oil and other liquids from leaking from the machine, enhancing safety during operation.
Q3: How does the CableLoc design benefit installation?
A3: The CableLoc design provides a robust connection with substantial pull strength, ensuring a secure and stable installation without requiring special tools.
Q4: Is the probe suitable for use in environments with high electromagnetic interference?
A4: Yes, the probe features enhanced RFI/EMI immunity, allowing it to operate reliably even in environments with significant interference.
Q5: Can this probe be used with older models from the 3300 series?
A5: Yes, the Bently Nevada 330101-00-61-15-12-05 Probe is fully compatible with earlier models in the 3300 series, facilitating seamless integration into existing systems.
